A Cutting-edge Library of 1857 SVG's for any Niagara-based Building Automation and Control System
ossGraphicsLibrary is compatible with any Niagara-based platform:
Niagara 4
IQ Vision
WEBs-N4
Arena NX
EC-Net 4
FX Workbench
Graphics Library for your Niagara BMS
Features
Watch how easy it is
BMS Graphic Examples
Browse examples and consult the full 1857 ossGraphicsLibrary Brochure
Frequently Asked Questions
Find answers to common questions about purchasing and using ossGraphicsLibrary
Get in touch with us using the contact form on this page and our fantastic team will handle your purchase. You can also email us on sales@onesight.solutions, or call on 020 3744 9539
Once payment has been confirmed, we will email you download links that include the SVG library JAR file, accompanying certificate for authorisation, the EULA, and some useful getting started links.
You can purchase and license the library by HostID.
The library is compatible with all Niagara 4-based platforms (version 4.10 or above), including Trend IQ Vision, Honeywell WEBs-N4, CentraLine Arena NX, ABB INTEGRA-Supervisor, Distech Controls EC-Net 4, and Johnson Controls FX Workbench.
The library’s time-saving features, including ready-to-use templates and pre-configured bindings, along with rapid compilation thanks to 5-pixel divisibility and snap-to-align functionality, significantly reduce engineering time and costs. This ensures your investment quickly pays off by freeing up valuable engineer hours.
Pre-configured templates are common system compositions, such as LTHW circuits and AHU arrangements. The library includes over 125 customisable templates to fast-track page assembly. To use them:
- Locate the ‘Pre-Configured Templates’ folder at the bottom of the ‘Palette’.
- Drag the folder into ‘Config’ within ‘Station’ in the ‘Nav’ side-menu, then click ‘Okay’.
- Select your desired template from the category drop-downs and open it in ‘Edit Mode’.
- In the ‘Widget Tree’, under the ‘Scroll Pane’ drop-down, copy the ‘Canvas Pane’.
- Open a PX page in ‘Edit Mode’ and paste the template into the ‘Scroll Pane’ in the ‘Widget Tree’.
The library is entirely composed of SVGs, ensuring flawlessly crisp and scalable visuals on any device or resolution. Modern interfaces require the cutting-edge versatility and future-ready capabilities that the SVG Asset Library provides. Additionally, the library aligns with evolving web technologies, making it a crucial component for contemporary systems.
