Metz BMT-AOP4

The Metz Connect BMT-AOP4 BACnet MS/TP IO module with 4 analog outputs was developed for decentralised switching tasks.

It is suitable as encoder for control variables, for example for electrical vent and mixing valves, valve positions, etc. The outputs can be output by means of standard objects via a BACnet client.

Compatibility

Niagara Framework and any BMS

GET A QUOTE

Share this product:

Features

Each output can be set for automatic or manual operation by means of 4 potentiometers at the front. The module is addressed and the baud rate is set by means of two address switches on the front. Suitable for decentralized mounting on DIN TH35 rail according to IEC 60715 in electrical distribution cabinets.

BACnet MS/TP

00 to F9

RS485 (two-wire bus)

9600 to 115200 bit/s

24 V AC/DC +/- 10 % (SELV)

50 mA (AC) / 20 mA (DC)

100 %

4 x analog

0 V to 10 V DC

5 mA at 10 V DC

0.3125 mV/digit

Green and red LED

35 x 69.3 x 60 mm

72 g

-5 °C to 55 °C

-20 °C to 70 °C

IP40 / IP20
